SAK-C868P-1SR BA
IC MCU 8BIT 8KB RAM 38TSSOPManufacturer: Infineon Technologies
Categories: Microcontrollers
Quality Control: Learn More
Infineon Technologies C5xx/C8xx Series microcontroller, part number SAK-C868P-1SR-BA, is an 8-bit MCU featuring a C800 core operating at 40MHz. This device offers 8KB of program memory (identified as RAM) and 512 x 8 bytes of data RAM. Peripherals include Brown-out Detect/Reset, PWM, and WDT, alongside 5x8-bit Analog-to-Digital converters. Connectivity options include UART/USART. The component is housed in a 38-TFSOP (0.173", 4.40mm Width) package, specifically the PG-TSSOP-38 supplier device package, suitable for surface mounting. It operates within a voltage range of 3V to 3.6V and a temperature range of -40°C to 125°C (TA). This microcontroller finds application in automotive, industrial, and consumer electronics sectors. The packaging is Tape & Reel (TR).
Additional Information
Series: C5xx/C8xxRoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: DiscontinuedPackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 38-TFSOP (0.173"", 4.40mm Width) |
| Mounting Type | Surface Mount |
| Speed | 40MHz |
| Program Memory Size | 8KB (8K x 8) |
| RAM Size | 512 x 8 |
| Operating Temperature | -40°C ~ 125°C (TA) |
| Oscillator Type | External |
| Program Memory Type | RAM |
| EEPROM Size | - |
| Core Processor | C800 |
| Data Converters | A/D 5x8b |
| Core Size | 8-Bit |
| Voltage - Supply (Vcc/Vdd) | 3V ~ 3.6V |
| Connectivity | UART/USART |
| Peripherals | Brown-out Detect/Reset, PWM, WDT |
| Supplier Device Package | PG-TSSOP-38 |
| Number of I/O | 18 |
| Programmable | Not Verified |
