S6J334CHFESE20000
TRAVEO-40NMManufacturer: Infineon Technologies
Categories: Microcontrollers
Quality Control: Learn More
Infineon Technologies S6J334CHFESE20000 is a 32-bit Traveo™ T1G series microcontroller featuring an ARM® Cortex®-R5F core operating at 240MHz. This device offers 2.0625MB of FLASH program memory and 544K x 8 RAM. Connectivity options include CANbus, CSIO, I2C, LINbus, and UART/USART. The S6J334CHFESE20000 includes 35x12b A/D converters, 112K x 8 EEPROM, and peripherals such as DMA, I2S, LVD, POR, PWM, and WDT. With 116 I/O lines, it is housed in a 144-TEQFP (20x20) package suitable for surface mounting. The operating temperature range is -40°C to 105°C. This microcontroller is commonly utilized in automotive applications.
Additional Information
Series: Traveo™ T1GRoHS Status: ROHS3 CompliantManufacturer Lead Time: 36 week(s)Product Status: ActivePackaging: TrayDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tray |
| Package / Case | 144-LQFP Exposed Pad |
| Mounting Type | Surface Mount |
| Speed | 240MHz |
| Program Memory Size | 2.0625MB (2.0625M x 8) |
| RAM Size | 544K x 8 |
| Operating Temperature | -40°C ~ 105°C (TA) |
| Oscillator Type | Internal |
| Program Memory Type | FLASH |
| EEPROM Size | 112K x 8 |
| Core Processor | ARM® Cortex®-R5F |
| Data Converters | A/D 35x12b |
| Core Size | 32-Bit |
| Voltage - Supply (Vcc/Vdd) | 3V ~ 3.6V |
| Connectivity | CANbus, CSIO, I2C, LINbus, UART/USART |
| Peripherals | DMA, I2S, LVD, POR, PWM, WDT |
| Supplier Device Package | 144-TEQFP (20x20) |
| Number of I/O | 116 |
