MB9BF366RPMC-G-JNE2
IC MCU 32BIT 544KB FLASH 120LQFPManufacturer: Infineon Technologies
Categories: Microcontrollers
Quality Control: Learn More
Infineon Technologies MB9BF366RPMC-G-JNE2 is an ARM Cortex-M4F microcontroller from the FM4 MB9B360R series. This 32-bit single-core device operates at 160MHz and features 544KB of FLASH program memory, organized as 544K x 8, and 64KB of RAM. It includes an A/D converter with 24 channels of 12-bit resolution and two 12-bit D/A converters. Connectivity options include CSIO, I2C, LINbus, UART/USART, and USB. On-chip peripherals consist of DMA, LVD, POR, PWM, and WDT. The component is housed in a 120-LQFP (16x16) surface-mount package. This microcontroller is suitable for applications in industrial automation, automotive systems, and general-purpose embedded control.
Additional Information
Series: FM4 MB9B360RRoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Bulk |
| Package / Case | 120-LQFP |
| Mounting Type | Surface Mount |
| Speed | 160MHz |
| Program Memory Size | 544KB (544K x 8) |
| RAM Size | 64K x 8 |
| Operating Temperature | -40°C ~ 125°C (TA) |
| Oscillator Type | Internal |
| Program Memory Type | FLASH |
| EEPROM Size | - |
| Core Processor | ARM® Cortex®-M4F |
| Data Converters | A/D 24x12b; D/A 2x12b |
| Core Size | 32-Bit Single-Core |
| Voltage - Supply (Vcc/Vdd) | 2.7V ~ 5.5V |
| Connectivity | CSIO, I2C, LINbus, UART/USART, USB |
| Peripherals | DMA, LVD, POR, PWM, WDT |
| Supplier Device Package | 120-LQFP (16x16) |
| Number of I/O | 100 |
| Programmable | Not Verified |
