MB90F463APMC-G-SNE1
IC MCU 16BIT 128KB FLASH 64LQFPManufacturer: Infineon Technologies
Categories: Microcontrollers
Quality Control: Learn More
The Infineon Technologies MB90F463APMC-G-SNE1 is a 16-bit microcontroller from the F²MC-16LX MB90460 series. This device features a 16MHz F²MC-16LX core and offers 128KB of FLASH program memory, organized as 128K x 8, alongside 2KB of internal RAM. Integrated peripherals include Power-On Reset (POR), Pulse Width Modulation (PWM), and Watchdog Timer (WDT). Connectivity is supported via UART/USART interfaces, and it incorporates 8x8/10-bit Analog-to-Digital (A/D) converters. The microcontroller is housed in a 64-LQFP (12x12mm) surface mount package. Operating within a temperature range of -40°C to 85°C, it requires an external oscillator and a supply voltage between 4.5V and 5.5V. This component is suitable for applications in industrial automation and automotive systems.
Additional Information
Series: F²MC-16LX MB90460RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDownload Free CAD Model:
Technical Details:
| Packaging | Bulk |
| Package / Case | 64-LQFP |
| Mounting Type | Surface Mount |
| Speed | 16MHz |
| Program Memory Size | 128KB (128K x 8) |
| RAM Size | 2K x 8 |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Oscillator Type | External |
| Program Memory Type | FLASH |
| EEPROM Size | - |
| Core Processor | F²MC-16LX |
| Data Converters | A/D 8x8/10b |
| Core Size | 16-Bit |
| Voltage - Supply (Vcc/Vdd) | 4.5V ~ 5.5V |
| Connectivity | UART/USART |
| Peripherals | POR, PWM, WDT |
| Supplier Device Package | 64-LQFP (12x12) |
| Number of I/O | 51 |
| Programmable | Not Verified |
