MB89P475-101PMC-GSE1
IC MCU 8BIT 16KB OTP 48LQFPManufacturer: Infineon Technologies
Categories: Microcontrollers
Quality Control: Learn More
Infineon Technologies F²MC-8L MB89470 8-Bit microcontroller, part number MB89P475-101PMC-GSE1. This component features an 8-bit F²MC-8L core operating at 12.5MHz. Program memory is 16KB of OTP, complemented by 512 x 8 bytes of RAM. On-chip peripherals include Power-On Reset (POR), Pulse Width Modulation (PWM), and Watchdog Timer (WDT). Connectivity options consist of Serial I/O and UART/USART. It integrates eight 10-bit Analog-to-Digital (A/D) converters. The device is supplied in a 48-LQFP (7x7) surface mount package and operates within a temperature range of -40°C to 85°C. This microcontroller is suitable for applications in the industrial and automotive sectors.
Additional Information
Series: F²MC-8L MB89470RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDownload Free CAD Model:
Technical Details:
| Packaging | Bulk |
| Package / Case | 48-LQFP |
| Mounting Type | Surface Mount |
| Speed | 12.5MHz |
| Program Memory Size | 16KB (16K x 8) |
| RAM Size | 512 x 8 |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Oscillator Type | External |
| Program Memory Type | OTP |
| EEPROM Size | - |
| Core Processor | F²MC-8L |
| Data Converters | A/D 8x10b |
| Core Size | 8-Bit |
| Voltage - Supply (Vcc/Vdd) | 3.5V ~ 5.5V |
| Connectivity | Serial I/O, UART/USART |
| Peripherals | POR, PWM, WDT |
| Supplier Device Package | 48-LQFP (7x7) |
| Number of I/O | 29 |
| Programmable | Not Verified |
