CY9BF118TBGL-GK7E1
IC MCU 32BIT 1MB FLASH 192FBGAManufacturer: Infineon Technologies
Categories: Microcontrollers
Quality Control: Learn More
Infineon Technologies FM3 MB9B110T series microcontroller, part number CY9BF118TBGL-GK7E1. This 32-bit ARM Cortex-M3 microcontroller features a 144MHz single-core processor with 1MB of FLASH program memory and 128KB of RAM. It offers extensive connectivity options including CSIO, EBI/EMI, I2C, LINbus, and UART/USART interfaces. The device includes 24 channels of 12-bit Analog-to-Digital converters and integrates peripherals such as DMA, LVD, POR, PWM, and WDT. The CY9BF118TBGL-GK7E1 is housed in a 192-FBGA (12x12) package, designed for surface mounting and operating within a temperature range of -40°C to 85°C. This component is suitable for applications in automotive, industrial automation, and consumer electronics markets.
Additional Information
Series: FM3 MB9B110TRoHS Status: ROHS3 CompliantManufacturer Lead Time: 26 week(s)Product Status: ActivePackaging: TrayDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tray |
| Package / Case | 192-LFBGA |
| Mounting Type | Surface Mount |
| Speed | 144MHz |
| Program Memory Size | 1MB (1M x 8) |
| RAM Size | 128K x 8 |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Oscillator Type | Internal |
| Program Memory Type | FLASH |
| EEPROM Size | - |
| Core Processor | ARM® Cortex®-M3 |
| Data Converters | A/D 24x12b |
| Core Size | 32-Bit Single-Core |
| Voltage - Supply (Vcc/Vdd) | 2.7V ~ 5.5V |
| Connectivity | CSIO, EBI/EMI, I2C, LINbus, UART/USART |
| Peripherals | DMA, LVD, POR, PWM, WDT |
| Supplier Device Package | 192-FBGA (12x12) |
| Number of I/O | 154 |
| Programmable | Not Verified |
