CY9AFA42LAQN-G-AVE2
IC MCU 32BIT 160KB 64VFQFNManufacturer: Infineon Technologies
Categories: Microcontrollers
Quality Control: Learn More
Infineon Technologies FM3 MB9AA40NB series microcontroller, part number CY9AFA42LAQN-G-AVE2. This 32-bit ARM Cortex-M3 core processor operates at 40MHz and features 160KB of FLASH program memory and 16KB of RAM. Connectivity options include CSIO, I2C, and UART/USART interfaces. The device is equipped with a 12-bit, 12-channel Analog-to-Digital converter. Peripherals include DMA, LCD controller, LVD, POR, PWM, and WDT. Supplied in a 64-VFQFN Exposed Pad package, this surface mount component operates within a temperature range of -40°C to 85°C. The supply voltage range is 1.65V to 3.6V. This microcontroller is suitable for applications in industrial automation, consumer electronics, and automotive systems.
Additional Information
Series: FM3 MB9AA40NBRoHS Status: ROHS3 CompliantManufacturer Lead Time: 26 week(s)Product Status: ActivePackaging: TrayDownload Free CAD Model:
Technical Details:
| Packaging | Tray |
| Package / Case | 64-VFQFN Exposed Pad |
| Mounting Type | Surface Mount |
| Speed | 40MHz |
| Program Memory Size | 160KB (160K x 8) |
| RAM Size | 16K x 8 |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Oscillator Type | Internal |
| Program Memory Type | FLASH |
| EEPROM Size | - |
| Core Processor | ARM® Cortex®-M3 |
| Data Converters | A/D 12x12b |
| Core Size | 32-Bit |
| Voltage - Supply (Vcc/Vdd) | 1.65V ~ 3.6V |
| Connectivity | CSIO, I2C, UART/USART |
| Peripherals | DMA, LCD, LVD, POR, PWM, WDT |
| Supplier Device Package | 64-QFN (9x9) |
| Number of I/O | 51 |
Request a Quote
