C167CSL16M3VCAFXQLA2
IC MCU 16BIT 144MQFPManufacturer: Infineon Technologies
Categories: Microcontrollers
Quality Control: Learn More
Infineon Technologies C16xx series microcontroller, part number C167CSL16M3VCAFXQLA2, features a 16-bit C166 core operating at 16MHz. This ROMless device is housed in a 144-pin P-MQFP-144-8 package, suitable for surface mounting. It offers 111 programmable I/O lines and includes a comprehensive peripheral set, such as POR, PWM, and WDT. Connectivity options are robust, supporting CANbus, EBI/EMI, SPI, SSC, and UART/USART interfaces. The integrated A/D converter provides 24 channels with 10-bit resolution. With 11K x 8 RAM, this component is designed for applications requiring advanced control and communication, commonly found in automotive and industrial automation sectors. It operates within a temperature range of -40°C to 85°C and requires a supply voltage between 4.5V and 5.5V.
Additional Information
Series: C16xxRoHS Status: unknownManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TrayDownload Free CAD Model:
Technical Details:
| Packaging | Tray |
| Package / Case | 144-BQFP |
| Mounting Type | Surface Mount |
| Speed | 16MHz |
| Program Memory Size | - |
| RAM Size | 11K x 8 |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Oscillator Type | External |
| Program Memory Type | ROMless |
| EEPROM Size | - |
| Core Processor | C166 |
| Data Converters | A/D 24x10b |
| Core Size | 16-Bit |
| Voltage - Supply (Vcc/Vdd) | 4.5V ~ 5.5V |
| Connectivity | CANbus, EBI/EMI, SPI, SSC, UART/USART |
| Peripherals | POR, PWM, WDT |
| Supplier Device Package | P-MQFP-144-8 |
| Number of I/O | 111 |
| Programmable | Not Verified |
