TLE4276GV10NTMA1

IC REG LIN 10V 400MA TO263-5-1

Categories: Linear, Low Drop Out (LDO) Regulators

Quality Control: Learn More

Infineon Technologies OPTIREG™ TLE4276GV10NTMA1 is a positive fixed 10V linear voltage regulator. This AEC-Q100 qualified device provides a regulated output of 400mA with a typical dropout voltage of 0.5V at 250mA. It features overcurrent, overtemperature, reverse polarity, and short-circuit protection. The quiescent current is 200 µA, with a supply current of up to 25 mA. The TLE4276GV10NTMA1 supports an input voltage range up to 40V and includes an inhibit function. Power dissipation is managed through its TO-263-5-1 surface-mount package. This component is suitable for automotive applications and is supplied in a Tape & Reel (TR) package. Its high PSRR of 54dB at 100Hz makes it ideal for noise-sensitive applications.

Additional Information

Series: OPTIREG™RoHS Status: RoHS non-compliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)

Download Free CAD Model:

Technical Details:

Packaging	Tape & Reel (TR)
Package / Case	TO-263-6, D2PAK (5 Leads + Tab), TO-263BA
Output Type	Fixed
Mounting Type	Surface Mount
Current - Output	400mA
Operating Temperature	-40°C ~ 150°C
Output Configuration	Positive
Current - Quiescent (Iq)	200 µA
Voltage - Input (Max)	40V
Number of Regulators	1
Supplier Device Package	PG-TO263-5-1
Voltage - Output (Max)	-
Voltage - Output (Min/Fixed)	10V
Control Features	Inhibit
Grade	Automotive
PSRR	54dB (100Hz)
Voltage Dropout (Max)	0.5V @ 250mA
Protection Features	Over Current, Over Temperature, Reverse Polarity, Short Circuit
Current - Supply (Max)	25 mA
Qualification	AEC-Q100
