IRU1205-25CLTR
IC REG LINEAR 2.5V 300MA SOT23-5Manufacturer: Infineon Technologies
Categories: Linear, Low Drop Out (LDO) Regulators
Quality Control: Learn More
Infineon Technologies IRU1205-25CLTR is a positive fixed linear voltage regulator designed for applications requiring stable 2.5V output. This SOT-23-5 packaged device delivers a continuous output current of 300mA, featuring a low dropout voltage of 0.4V at the maximum output current. Enhanced protection mechanisms include over-current and over-temperature shutdown. The regulator is suitable for surface-mount assembly and operates within a temperature range of 0°C to 125°C. Its primary application areas include consumer electronics and industrial control systems. The component is supplied in a Tape & Reel (TR) package.
Additional Information
Series: -RoHS Status: RoHS non-compliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | SC-74A, SOT-753 |
| Output Type | Fixed |
| Mounting Type | Surface Mount |
| Current - Output | 300mA |
| Operating Temperature | 0°C ~ 125°C |
| Output Configuration | Positive |
| Voltage - Input (Max) | 10V |
| Number of Regulators | 1 |
| Supplier Device Package | SOT-23-5 |
| Voltage - Output (Max) | - |
| Voltage - Output (Min/Fixed) | 2.5V |
| Control Features | Enable |
| PSRR | - |
| Voltage Dropout (Max) | 0.4V @ 300mA |
| Protection Features | Over Current, Over Temperature |
