TLE4242GATMA3

IC LED DRV LIN PWM 500MA TO263-7

Quality Control: Learn More

The Infineon Technologies TLE4242GATMA3 is a linear LED driver featuring PWM dimming control for precise illumination management. This automotive-grade component delivers up to 500mA output current per channel, supporting a wide supply voltage range from 4.5V to 42V. Its integrated switch simplifies system design, and the 1 output configuration is ideal for single-channel LED applications. The TLE4242GATMA3 is supplied in a PG-TO263-7-1 package, suitable for surface mount assembly. This device finds application in automotive lighting systems, where reliable and efficient LED control is paramount. The operating temperature range of -40°C to 150°C ensures robust performance in demanding environments.

Additional Information

Series: LITIX™RoHS Status: ROHS3 CompliantManufacturer Lead Time: 89 week(s)Product Status: Last Time BuyPackaging: Tape & Reel (TR)

Download Free CAD Model:

Technical Details:

Packaging	Tape & Reel (TR)
Package / Case	TO-263-8, D2PAK (7 Leads + Tab), TO-263CA
Voltage - Output	4V
Mounting Type	Surface Mount
Number of Outputs	1
Frequency	-
Type	Linear
Operating Temperature	-40°C ~ 150°C (TJ)
Applications	-
Current - Output / Channel	500mA
Internal Switch(s)	Yes
Topology	-
Supplier Device Package	PG-TO263-7-1
Dimming	PWM
Voltage - Supply (Min)	4.5V
Voltage - Supply (Max)	42V
Grade	Automotive
