TLE4242GATMA1

IC LED DRIVER LINEAR DIM TO263-7

Quality Control: Learn More

The Infineon Technologies TLE4242GATMA1 is a high-performance linear LED driver designed for demanding lighting applications. This single-output device offers integrated PWM dimming capabilities, allowing precise control of LED brightness. With an output current capability of 500mA per channel and a maximum output voltage of 40V, it is well-suited for driving various LED arrays. The TLE4242GATMA1 operates from a supply voltage range of 4.5V to 42V, accommodating a broad spectrum of power sources. Its internal switch design simplifies circuit implementation. Packaged in a PG-TO263-7-1 (TO-263-8, D2PAK) surface-mount package, it is supplied on tape and reel for efficient automated assembly. This component is commonly found in automotive lighting systems and general illumination solutions requiring robust LED control. The operating temperature range is -40°C to 150°C (TJ).

Additional Information

Series: -RoHS Status: unknownManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)

Download Free CAD Model:

Technical Details:

Packaging	Tape & Reel (TR)
Package / Case	TO-263-8, D2PAK (7 Leads + Tab), TO-263CA
Voltage - Output	40V
Mounting Type	Surface Mount
Number of Outputs	1
Frequency	-
Type	Linear
Operating Temperature	-40°C ~ 150°C (TJ)
Applications	-
Current - Output / Channel	500mA
Internal Switch(s)	Yes
Topology	-
Supplier Device Package	PG-TO263-7-1
Dimming	PWM
Voltage - Supply (Min)	4.5V
Voltage - Supply (Max)	42V
