TLE4241GM

IC LED DRVR LINEAR PWM 60MA 8DSO

Quality Control: Learn More

Infineon Technologies TLE4241GM is a single-output linear LED driver IC designed for precise PWM dimming control. This device is capable of sourcing up to 60mA from a single output channel, with a maximum output voltage of 40V and a supply voltage range from 4V to 45V. Featuring an integrated switch and operating across a junction temperature range of -40°C to 150°C, the TLE4241GM is suitable for demanding applications. It is housed in an 8-pin PG-DSO-8-9 package, commonly known as 8-SOIC, and is supplied in a Tape & Reel (TR) configuration for surface mounting. This component is utilized in automotive lighting and general lighting systems requiring efficient and reliable LED current regulation.

Additional Information

Series: -RoHS Status: unknownManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:

Download Free CAD Model:

Technical Details:

Packaging	Tape & Reel (TR)
Package / Case	8-SOIC (0.154"", 3.90mm Width)
Voltage - Output	40V
Mounting Type	Surface Mount
Number of Outputs	1
Frequency	-
Type	Linear
Operating Temperature	-40°C ~ 150°C (TJ)
Applications	-
Current - Output / Channel	60mA
Internal Switch(s)	Yes
Topology	-
Supplier Device Package	PG-DSO-8-9
Dimming	PWM
Voltage - Supply (Min)	4V
Voltage - Supply (Max)	45V
