FZ1200R33KF2CNOSA1
IGBT MODULE 3300V 2000AManufacturer: Infineon Technologies
Categories: IGBT Modules
Quality Control: Learn More
The Infineon Technologies IGBT Module, part number FZ1200R33KF2CNOSA1, is a high-power full bridge configuration module designed for demanding applications. This component offers a robust 3300 V collector-emitter breakdown voltage and a maximum collector current of 2000 A, with a power dissipation capability of 14500 W. Featuring a chassis mount for efficient thermal management, it operates within an industrial temperature range of -40°C to 125°C. The module's input capacitance is specified at 150 nF at 25 V, and the Vce(on) is a maximum of 4.25V at 15V and 1200A. This device is a critical component in high-voltage power conversion systems across industries such as renewable energy, industrial motor drives, and electric vehicle powertrains.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Bulk |
| Package / Case | Module |
| Mounting Type | Chassis Mount |
| Input | Standard |
| Configuration | Full Bridge |
| Operating Temperature | -40°C ~ 125°C |
| Vce(on) (Max) @ Vge, Ic | 4.25V @ 15V, 1200A |
| NTC Thermistor | No |
| Supplier Device Package | Module |
| IGBT Type | - |
| Current - Collector (Ic) (Max) | 2000 A |
| Voltage - Collector Emitter Breakdown (Max) | 3300 V |
| Power - Max | 14500 W |
| Current - Collector Cutoff (Max) | 12 mA |
| Input Capacitance (Cies) @ Vce | 150 nF @ 25 V |
