FS75R07U1E4BPSA1
IGBT MOD 650V 100A 275WManufacturer: Infineon Technologies
Categories: IGBT Modules
Quality Control: Learn More
Infineon Technologies FS75R07U1E4BPSA1 is a SmartPACK 1 series IGBT module featuring a full bridge configuration. This Trench Field Stop IGBT technology offers a robust 650 V breakdown voltage and a continuous collector current capability of 100 A, with a maximum power dissipation of 275 W. The module exhibits a low collector-emitter saturation voltage of 1.95 V at 15 V gate-emitter voltage and 75 A collector current, and a typical input capacitance (Cies) of 4.6 nF at 25 V. Designed for chassis mounting, it includes an integrated NTC thermistor for thermal monitoring. The FS75R07U1E4BPSA1 is suitable for demanding applications in industrial power supplies, motor drives, and renewable energy systems. It operates reliably within a temperature range of -40°C to 150°C.
Additional Information
Series: SmartPACK1RoHS Status: ROHS3 CompliantManufacturer Lead Time: 26 week(s)Product Status: Not For New DesignsPackaging: TrayDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tray |
| Package / Case | Module |
| Mounting Type | Chassis Mount |
| Input | Standard |
| Configuration | Full Bridge |
| Operating Temperature | -40°C ~ 150°C |
| Vce(on) (Max) @ Vge, Ic | 1.95V @ 15V, 75A |
| NTC Thermistor | Yes |
| Supplier Device Package | Module |
| IGBT Type | Trench Field Stop |
| Current - Collector (Ic) (Max) | 100 A |
| Voltage - Collector Emitter Breakdown (Max) | 650 V |
| Power - Max | 275 W |
| Current - Collector Cutoff (Max) | 1 mA |
| Input Capacitance (Cies) @ Vce | 4.6 nF @ 25 V |
