FS450R12KE3BOSA1
IGBT MOD 1200V 600A 2100WManufacturer: Infineon Technologies
Categories: IGBT Modules
Quality Control: Learn More
Infineon Technologies FS450R12KE3BOSA1 is a Trench Field Stop IGBT Module designed for high-power applications. This module features a 1200V collector-emitter breakdown voltage and a maximum collector current of 600A, with a power dissipation capability of 2100W. The Vce(on) is specified at a maximum of 2.15V at 15V Vge and 450A Ic. It includes an integrated NTC thermistor for thermal management and a chassis mount for robust integration. The input capacitance (Cies) is 32 nF at 25V. This component is suitable for demanding industrial applications including electric vehicle powertrains and industrial motor drives. The FS450R12KE3BOSA1 is packaged in a Module format for tray distribution.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: 16 week(s)Product Status: Not For New DesignsPackaging: TrayDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tray |
| Package / Case | Module |
| Mounting Type | Chassis Mount |
| Input | Standard |
| Configuration | Three Phase Inverter |
| Operating Temperature | -40°C ~ 125°C (TJ) |
| Vce(on) (Max) @ Vge, Ic | 2.15V @ 15V, 450A |
| NTC Thermistor | Yes |
| Supplier Device Package | Module |
| IGBT Type | Trench Field Stop |
| Current - Collector (Ic) (Max) | 600 A |
| Voltage - Collector Emitter Breakdown (Max) | 1200 V |
| Power - Max | 2100 W |
| Current - Collector Cutoff (Max) | 5 mA |
| Input Capacitance (Cies) @ Vce | 32 nF @ 25 V |
