FF800R17KE3B2NOSA1
IGBT MODULE 1700V 800AManufacturer: Infineon Technologies
Categories: IGBT Modules
Quality Control: Learn More
Infineon Technologies IGBT Module FF800R17KE3B2NOSA1 from the IHM-B series. This module features 2 independent IGBTs with a maximum collector-emitter voltage of 1700 V. It offers a continuous collector current (Ic) capability of 1200 A and a maximum power dissipation of 5200 W. The module utilizes a standard input and has a Vce(on) of 2.45V at 15V gate-emitter voltage and 800A collector current. Input capacitance (Cies) is 72 nF at 25 V. Designed for chassis mounting, this component operates within an ambient temperature range of -40°C to 125°C. Its robust construction and high power handling make it suitable for applications in industrial motor drives and renewable energy systems.
Additional Information
Series: IHM-BRoHS Status: unknownManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDownload Free CAD Model:
Technical Details:
| Packaging | Bulk |
| Package / Case | Module |
| Mounting Type | Chassis Mount |
| Input | Standard |
| Configuration | 2 Independent |
| Operating Temperature | -40°C ~ 125°C (TJ) |
| Vce(on) (Max) @ Vge, Ic | 2.45V @ 15V, 800A |
| NTC Thermistor | No |
| Supplier Device Package | A-IHV130-3 |
| IGBT Type | - |
| Current - Collector (Ic) (Max) | 1200 A |
| Voltage - Collector Emitter Breakdown (Max) | 1700 V |
| Power - Max | 5200 W |
| Current - Collector Cutoff (Max) | 5 mA |
| Input Capacitance (Cies) @ Vce | 72 nF @ 25 V |
