FF75R12RT4HOSA1
IGBT MOD 1200V 75A 395WManufacturer: Infineon Technologies
Categories: IGBT Modules
Quality Control: Learn More
Infineon Technologies FF75R12RT4HOSA1 is a PrimePACK™2 series IGBT module. This Trench Field Stop IGBT features a 1200V collector-emitter breakdown voltage and a maximum collector current of 75A. The module boasts a low Vce(on) of 2.15V at 15V Vge and 75A Ic, with a maximum power dissipation of 395W. Its configuration includes two independent IGBTs, and it is designed for chassis mounting. The FF75R12RT4HOSA1 has a typical input capacitance (Cies) of 4.3 nF at 25V. This component operates across an ambient temperature range of -40°C to 150°C. It is commonly utilized in industrial motor drives, renewable energy systems, and power supply applications. The device is supplied in tray packaging.
Additional Information
Series: PrimePACK™2RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TrayDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tray |
| Package / Case | Module |
| Mounting Type | Chassis Mount |
| Input | Standard |
| Configuration | 2 Independent |
| Operating Temperature | -40°C ~ 150°C |
| Vce(on) (Max) @ Vge, Ic | 2.15V @ 15V, 75A |
| NTC Thermistor | No |
| Supplier Device Package | Module |
| IGBT Type | Trench Field Stop |
| Current - Collector (Ic) (Max) | 75 A |
| Voltage - Collector Emitter Breakdown (Max) | 1200 V |
| Power - Max | 395 W |
| Current - Collector Cutoff (Max) | 1 mA |
| Input Capacitance (Cies) @ Vce | 4.3 nF @ 25 V |
Request a Quote
