DDB6U50N16W1RPBPSA1
LOW POWER EASY AG-EASY1B-711Manufacturer: Infineon Technologies
Categories: IGBT Modules
Quality Control: Learn More
Infineon Technologies DDB6U50N16W1RPBPSA1 is a Trench Field Stop IGBT module featuring a single chopper configuration. This component offers a 1200 V collector-emitter breakdown voltage and a 50 A continuous collector current. The module is designed for chassis mounting and utilizes the AG-EASY1B package. Key electrical parameters include a maximum Vce(on) of 1.5 V at 15 V gate voltage and 50 A collector current, and an input capacitance (Cies) of 11.1 nF at 25 V. The operating temperature range is -40°C to 175°C (TJ). This device is suitable for applications in industrial power supplies and motor drives.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: 20 week(s)Product Status: ActivePackaging: TrayDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tray |
| Package / Case | Module |
| Mounting Type | Chassis Mount |
| Input | Three Phase Bridge Rectifier |
| Configuration | Single Chopper |
| Operating Temperature | -40°C ~ 175°C (TJ) |
| Vce(on) (Max) @ Vge, Ic | 1.5V @ 15V, 50A |
| NTC Thermistor | No |
| Supplier Device Package | AG-EASY1B |
| IGBT Type | Trench Field Stop |
| Current - Collector (Ic) (Max) | 50 A |
| Voltage - Collector Emitter Breakdown (Max) | 1200 V |
| Current - Collector Cutoff (Max) | 6.2 µA |
| Input Capacitance (Cies) @ Vce | 11.1 nF @ 25 V |
