6MS30017E43W34404NOSA1
IGBT MODULE 1700V 4280AManufacturer: Infineon Technologies
Categories: IGBT Modules
Quality Control: Learn More
Infineon Technologies ModSTACK™ HD IGBT Module, part number 6MS30017E43W34404NOSA1, is a three-phase inverter configuration designed for high-power applications. This chassis mount module offers a robust 1700 V collector-emitter breakdown voltage and a maximum collector current of 4280 A, with a power dissipation capability of 32300 W. Featuring an integrated NTC thermistor for thermal management and a standard input, this IGBT module is suitable for demanding industrial power conversion systems, including motor drives, renewable energy inverters, and industrial power supplies. The module is supplied in tray packaging.
Additional Information
Series: ModSTACK™ HDRoHS Status: RoHS Compliant By ExemptionManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TrayDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tray |
| Package / Case | Module |
| Mounting Type | Chassis Mount |
| Input | Standard |
| Configuration | Three Phase Inverter |
| Operating Temperature | -25°C ~ 55°C |
| Vce(on) (Max) @ Vge, Ic | - |
| NTC Thermistor | Yes |
| Supplier Device Package | Module |
| IGBT Type | - |
| Current - Collector (Ic) (Max) | 4280 A |
| Voltage - Collector Emitter Breakdown (Max) | 1700 V |
| Power - Max | 32300 W |
