PX3516ADDGR4XTMA1
IC GATE DRVR HALF-BRDG TDSON10-2Manufacturer: Infineon Technologies
Categories: Gate Drivers
Quality Control: Learn More
The Infineon Technologies PX3516ADDGR4XTMA1 is a half-bridge gate driver IC, featuring a non-inverting input and designed for N-channel MOSFETs. This PG-TDSON-10-2 packaged component offers synchronous channel operation and supports a high-side bootstrap voltage up to 30V. With a supply voltage range of 4.5V to 6V, it delivers peak output currents of 2A for both source and sink. The device boasts typical rise and fall times of 10ns, facilitating efficient switching. Its surface mount configuration within a 10-VFDFN exposed pad package, supplied on tape and reel, makes it suitable for automated assembly. Applications for this component can be found in power electronics, motor control, and power supply systems. The logic voltage thresholds are specified as 1.3V for VIL and 1.9V for VIH. It operates reliably within an extended temperature range of -25°C to 150°C (TJ).
Additional Information
Series: -RoHS Status: unknownManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 10-VFDFN Exposed Pad |
| Mounting Type | Surface Mount |
| Operating Temperature | -25°C ~ 150°C (TJ) |
| Voltage - Supply | 4.5V ~ 6V |
| Input Type | Non-Inverting |
| High Side Voltage - Max (Bootstrap) | 30 V |
| Supplier Device Package | PG-TDSON-10-2 |
| Rise / Fall Time (Typ) | 10ns, 10ns |
| Channel Type | Synchronous |
| Driven Configuration | Half-Bridge |
| Number of Drivers | 2 |
| Gate Type | N-Channel MOSFET |
| Logic Voltage - VIL, VIH | 1.3V, 1.9V |
| Current - Peak Output (Source, Sink) | 2A, 2A |
| Programmable | Not Verified |
