IR2155PBF

IC GATE DRVR HALF-BRIDGE 8DIP

Manufacturer: Infineon Technologies

Categories: Gate Drivers

Quality Control: Learn More

Infineon Technologies' IR2155PBF is an 8-pin DIP Half-Bridge Gate Driver IC featuring an integrated RC oscillator input circuit. This device is engineered for driving power MOSFETs and IGBTs in half-bridge configurations. It offers a high-side voltage capability up to 600V, with peak output currents of 250mA sourcing and 500mA sinking. The driver is designed for operation with supply voltages ranging from 10V to 20V. Typical rise and fall times are 80ns and 45ns, respectively. The IR2155PBF is suitable for applications in power supplies, motor control, and lighting. Its through-hole mounting type and 8-PDIP package facilitate straightforward integration into various circuit designs. The operating temperature range is -40°C to 150°C.

Additional Information

Series: -RoHS Status: unknownManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TubeDatasheet:
Technical Details:
PackagingTube
Package / Case8-DIP (0.300"", 7.62mm)
Mounting TypeThrough Hole
Operating Temperature-40°C ~ 150°C (TJ)
Voltage - Supply10V ~ 20V
Input TypeRC Input Circuit
High Side Voltage - Max (Bootstrap)600 V
Supplier Device Package8-PDIP
Rise / Fall Time (Typ)80ns, 45ns
Channel TypeSynchronous
Driven ConfigurationHalf-Bridge
Number of Drivers2
Gate TypeIGBT, N-Channel MOSFET
Logic Voltage - VIL, VIH-
Current - Peak Output (Source, Sink)250mA, 500mA
ProgrammableNot Verified
