IR2137J
IC GATE DRVR HALF-BRIDGE 68PLCCManufacturer: Infineon Technologies
Categories: Gate Drivers
Quality Control: Learn More
Infineon Technologies IR2137J is a 3-phase half-bridge gate driver IC. This device is designed for driving high-voltage IGBTs and MOSFETs, offering robust performance in demanding applications. Featuring an inverting input, the IR2137J supports a bootstrap voltage up to 600V, enabling efficient operation of high-side power switches. The IC integrates three independent gate driver channels, each capable of delivering high peak output currents for fast switching transitions, with typical rise and fall times of 115ns and 25ns respectively. Operating over a wide temperature range from -40°C to 150°C, it is housed in a 68-PLCC surface-mount package. The IR2137J is commonly utilized in motor control systems, power supplies, and industrial automation where reliable and efficient power switching is critical. The supply voltage range is 12.5V to 20V.
Additional Information
Series: -RoHS Status: RoHS non-compliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TubeDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tube |
| Package / Case | 68-PLCC |
| Mounting Type | Surface Mount |
| Operating Temperature | -40°C ~ 150°C (TJ) |
| Voltage - Supply | 12.5V ~ 20V |
| Input Type | Inverting |
| High Side Voltage - Max (Bootstrap) | 600 V |
| Supplier Device Package | 68-PLCC (24.23x24.23) |
| Rise / Fall Time (Typ) | 115ns, 25ns |
| Channel Type | 3-Phase |
| Driven Configuration | Half-Bridge |
| Number of Drivers | 3 |
| Gate Type | IGBT |
| Logic Voltage - VIL, VIH | - |
| Current - Peak Output (Source, Sink) | - |
| Programmable | Not Verified |
