IR2125
IC GATE DRVR HIGH-SIDE 8DIPManufacturer: Infineon Technologies
Categories: Gate Drivers
Quality Control: Learn More
Infineon Technologies IR2125 is a high-side gate driver IC featuring a single, non-inverting channel. This component is designed for driving IGBTs and N-channel MOSFETs in high-side configurations. It offers a maximum bootstrap voltage of 500V and operates with a supply voltage range of 0V to 18V. The IR2125 provides peak output currents of 1.6A source and 3.3A sink, with typical rise and fall times of 43ns and 26ns respectively. Logic input levels are specified with VIL at 0.8V and VIH at 2.2V. The device is housed in an 8-PDIP package suitable for through-hole mounting. Its robust design makes it suitable for applications in power electronics, industrial motor control, and power supply systems. The operating temperature range is -40°C to 150°C.
Additional Information
Series: -RoHS Status: RoHS non-compliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TubeDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tube |
| Package / Case | 8-DIP (0.300"", 7.62mm) |
| Mounting Type | Through Hole |
| Operating Temperature | -40°C ~ 150°C (TJ) |
| Voltage - Supply | 0V ~ 18V |
| Input Type | Non-Inverting |
| High Side Voltage - Max (Bootstrap) | 500 V |
| Supplier Device Package | 8-PDIP |
| Rise / Fall Time (Typ) | 43ns, 26ns |
| Channel Type | Single |
| Driven Configuration | High-Side |
| Number of Drivers | 1 |
| Gate Type | IGBT, N-Channel MOSFET |
| Logic Voltage - VIL, VIH | 0.8V, 2.2V |
| Current - Peak Output (Source, Sink) | 1.6A, 3.3A |
| Programmable | Not Verified |
