IR2113SPBF
IC GATE DRVR HALF-BRIDGE 16SOICManufacturer: Infineon Technologies
Categories: Gate Drivers
Quality Control: Learn More
Infineon Technologies IR2113SPBF is a high-voltage, high-speed power MOSFET and IGBT gate driver. This device features a half-bridge configuration with two independent, non-inverting channels. Each channel is capable of sourcing and sinking 2A of peak output current, facilitating rapid switching transitions with typical rise and fall times of 25ns and 17ns respectively. The high-side voltage, utilized for bootstrap operation, can reach up to 600V, while the supply voltage range is 3.3V to 20V. Logic voltage thresholds for input signals are specified at 6V (VIL) and 9.5V (VIH). Designed for surface mounting, the IR2113SPBF is housed in a 16-SOIC package with a 7.50mm width, suitable for operation across an extended temperature range of -40°C to 150°C. This component finds application in power conversion systems, motor control, and industrial power supplies.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: 20 week(s)Product Status: Not For New DesignsPackaging: TubeDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tube |
| Package / Case | 16-SOIC (0.295"", 7.50mm Width) |
| Mounting Type | Surface Mount |
| Operating Temperature | -40°C ~ 150°C (TJ) |
| Voltage - Supply | 3.3V ~ 20V |
| Input Type | Non-Inverting |
| High Side Voltage - Max (Bootstrap) | 600 V |
| Supplier Device Package | 16-SOIC |
| Rise / Fall Time (Typ) | 25ns, 17ns |
| Channel Type | Independent |
| Driven Configuration | Half-Bridge |
| Number of Drivers | 2 |
| Gate Type | IGBT, N-Channel MOSFET |
| Logic Voltage - VIL, VIH | 6V, 9.5V |
| Current - Peak Output (Source, Sink) | 2A, 2A |
| Programmable | Not Verified |
