AUIRS2127S
IC GATE DRVR HIGH-SIDE 8SOICManufacturer: Infineon Technologies
Categories: Gate Drivers
Quality Control: Learn More
Infineon Technologies AUIRS2127S is a high-side gate driver IC featuring a single, non-inverting channel. This AEC-Q100 qualified component is designed for surface mount applications within an 8-SOIC package, offering robust performance with a maximum bootstrap voltage of 600V. It supports IGBT and N-Channel MOSFET gate drive requirements, delivering peak output currents of 290mA source and 600mA sink. The driver operates with supply voltages ranging from 12V to 20V, and its logic inputs are compatible with 0.8V (VIL) and 2.5V (VIH). Typical rise and fall times are 80ns and 40ns, respectively. The AUIRS2127S is suitable for demanding automotive applications due to its extended operating temperature range of -40°C to 150°C.
Additional Information
Series: -RoHS Status: unknownManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TubeDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tube |
| Package / Case | 8-SOIC (0.154"", 3.90mm Width) |
| Mounting Type | Surface Mount |
| Operating Temperature | -40°C ~ 150°C (TJ) |
| Voltage - Supply | 12V ~ 20V |
| Input Type | Non-Inverting |
| High Side Voltage - Max (Bootstrap) | 600 V |
| Supplier Device Package | 8-SOIC |
| Rise / Fall Time (Typ) | 80ns, 40ns |
| Channel Type | Single |
| Driven Configuration | High-Side |
| Number of Drivers | 1 |
| Gate Type | IGBT, N-Channel MOSFET |
| Logic Voltage - VIL, VIH | 0.8V, 2.5V |
| Current - Peak Output (Source, Sink) | 290mA, 600mA |
| Grade | Automotive |
| Programmable | Not Verified |
| Qualification | AEC-Q100 |
