6ED2231S12TXUMA1
IC GATE DRVR HALF-BRIDGE 28SOICManufacturer: Infineon Technologies
Categories: Gate Drivers
Quality Control: Learn More
Half-Bridge Gate Driver IC Non-Inverting PG-DSO-24-21
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: 12 week(s)Product Status: ActivePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 28-SOIC (0.295"", 7.50mm Width), 24 Leads |
| Mounting Type | Surface Mount |
| Operating Temperature | -40°C ~ 125°C (TA) |
| Voltage - Supply | 13V ~ 20V |
| Input Type | Non-Inverting |
| High Side Voltage - Max (Bootstrap) | 1200 V |
| Supplier Device Package | PG-DSO-24-21 |
| Rise / Fall Time (Typ) | 35ns, 20ns |
| Channel Type | 3-Phase |
| Driven Configuration | Half-Bridge |
| Number of Drivers | 6 |
| Gate Type | IGBT, SiC MOSFET |
| Logic Voltage - VIL, VIH | 0.7V, 2.3V |
| Current - Peak Output (Source, Sink) | 350mA, 650mA |
| Programmable | Not Verified |
