2ED21844S06JXUMA1
IC GATE DRVR HALF-BRIDGE 14SOICManufacturer: Infineon Technologies
Categories: Gate Drivers
Quality Control: Learn More
Infineon Technologies 2ED21844S06JXUMA1 is a half-bridge gate driver IC designed for advanced power control applications. This non-inverting device features synchronous channel operation and is packaged in a 14-SOIC (PG-DSO-14-49) for surface mount integration. It provides robust performance with peak output currents of 2.5A for both source and sink, enabling efficient driving of IGBT and N-Channel MOSFET power transistors. The high-side voltage capability reaches up to 650V, facilitated by an integrated bootstrap function. With a supply voltage range of 10V to 20V and typical rise/fall times of 15ns, this component is well-suited for demanding sectors including industrial automation, electric vehicle powertrains, and renewable energy systems. The operating temperature range is -40°C to 125°C.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: 16 week(s)Product Status: ActivePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 14-SOIC (0.154"", 3.90mm Width) |
| Mounting Type | Surface Mount |
| Operating Temperature | -40°C ~ 125°C (TA) |
| Voltage - Supply | 10V ~ 20V |
| Input Type | Non-Inverting |
| High Side Voltage - Max (Bootstrap) | 650 V |
| Supplier Device Package | PG-DSO-14-49 |
| Rise / Fall Time (Typ) | 15ns, 15ns |
| Channel Type | Synchronous |
| Driven Configuration | Half-Bridge |
| Number of Drivers | 1 |
| Gate Type | IGBT, N-Channel MOSFET |
| Logic Voltage - VIL, VIH | 1.1V, 1.7V |
| Current - Peak Output (Source, Sink) | 2.5A, 2.5A |
| Programmable | Not Verified |
