IRSM515-035PATR
IC HALF BRIDGE DRIVER 2.1A 23SOPManufacturer: Infineon Technologies
Categories: Full Half-Bridge (H Bridge) Drivers
Quality Control: Learn More
Infineon Technologies µIPM™-DIP series IRSM515-035PATR is a Half Bridge driver designed for AC motor control applications. This UMOS technology device offers an output configuration of three half-bridges, with each channel capable of delivering 2.1A continuous output current and a peak output of 15A. The IRSM515-035PATR features a bootstrap circuit for efficient high-side driving and includes under-voltage lock-out (UVLO) for fault protection. It is designed for inductive load types and integrates a logic interface. The component operates with a load voltage up to 400V (Max) and a supply voltage range of 13.5V to 16.5V. The typical on-resistance (Rds On) is 1.8 Ohm. This component is supplied in a 23-SOP package, presented on tape and reel (TR). It is suitable for operation across an extended temperature range of -40°C to 150°C (TJ).
Additional Information
Series: µIPM™-DIPRoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Features | Bootstrap Circuit |
| Packaging | Tape & Reel (TR) |
| Package / Case | 23-PowerSMD Module |
| Mounting Type | Surface Mount |
| Interface | Logic |
| Operating Temperature | -40°C ~ 150°C (TJ) |
| Output Configuration | Half Bridge (3) |
| Voltage - Supply | 13.5V ~ 16.5V |
| Rds On (Typ) | 1.8Ohm |
| Applications | AC Motors |
| Current - Output / Channel | 2.1A |
| Current - Peak Output | 15A |
| Technology | UMOS |
| Voltage - Load | 400V (Max) |
| Supplier Device Package | 23-SOP |
| Fault Protection | UVLO |
| Load Type | Inductive |
