IRSM005-301MHTR
IC HALF BRIDGE DRIVER 30A 27QFNManufacturer: Infineon Technologies
Categories: Full Half-Bridge (H Bridge) Drivers
Quality Control: Learn More
Infineon Technologies µIPM™ IRSM005-301MHTR is a Half Bridge Driver designed for high-performance power applications. This component features a 30A output current capability and operates with a supply voltage range of 10V to 20V. The IRSM005-301MHTR is built on Power MOSFET technology and offers a low on-resistance of 16mOhm (typ). Its 27-PQFN (7x8) package facilitates surface mounting and is supplied on tape and reel. Integrated fault protection includes Under Voltage Lockout (UVLO), and the design incorporates a bootstrap circuit for efficient high-side driver operation. Typical applications include AC motors, DC motors, DC-DC converters, and general-purpose power management. The device is qualified for operation at an ambient temperature of up to 150°C (TJ).
Additional Information
Series: µIPM™RoHS Status: ROHS3 CompliantManufacturer Lead Time: 27 week(s)Product Status: ActivePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Features | Bootstrap Circuit |
| Packaging | Tape & Reel (TR) |
| Package / Case | 27-PowerVQFN |
| Mounting Type | Surface Mount |
| Interface | Logic |
| Operating Temperature | 150°C (TJ) |
| Output Configuration | Half Bridge |
| Voltage - Supply | 10V ~ 20V |
| Rds On (Typ) | 16mOhm |
| Applications | AC Motors, DC Motors, DC-DC Converters, General Purpose |
| Current - Output / Channel | 30A |
| Current - Peak Output | - |
| Technology | Power MOSFET |
| Voltage - Load | 100V (Max) |
| Supplier Device Package | 27-PQFN (7x8) |
| Fault Protection | UVLO |
| Load Type | Inductive, Capacitive |
| Grade | - |
| Qualification | - |
