IR51H310
IC HALF BRIDGE DRIVER 700MA 9SIPManufacturer: Infineon Technologies
Categories: Full Half-Bridge (H Bridge) Drivers
Quality Control: Learn More
Infineon Technologies IR51H310, a half-bridge driver, is designed for AC motor control applications. This component, housed in a 9-SIP, 7-lead package, facilitates the driving of power MOSFETs with a load voltage capability up to 400V. The device features a 700mA output current per channel and integrates internal oscillators for simplified control. Fault protection is provided via Undervoltage Lockout (UVLO). The supply voltage range is 10V to 15.6V, with the device operating across a junction temperature range of -55°C to 150°C. The load type is inductive, and the mounting type is through hole. This component is suitable for demanding industrial environments.
Additional Information
Series: -RoHS Status: RoHS non-compliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TubeDatasheet:Download Free CAD Model:
Technical Details:
| Features | Internal Oscillators |
| Packaging | Tube |
| Package / Case | 9-SIP, 7 Leads |
| Mounting Type | Through Hole |
| Interface | ON/OFF |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Output Configuration | Half Bridge |
| Voltage - Supply | 10V ~ 15.6V |
| Rds On (Typ) | 1.8Ohm |
| Applications | AC Motors |
| Current - Output / Channel | 700mA |
| Current - Peak Output | - |
| Technology | Power MOSFET |
| Voltage - Load | 400V (Max) |
| Supplier Device Package | 9-SIP, 7 Leads |
| Fault Protection | UVLO |
| Load Type | Inductive |
