FF3MR12KM1HPHPSA1
FF3MR12KM1HPHPSA1Manufacturer: Infineon Technologies
Categories: FET, MOSFET Arrays
Quality Control: Learn More
Mosfet Array 1200V (1.2kV) 220A Chassis Mount AG-62MMHB
Additional Information
Series: CoolSiC™RoHS Status: ROHS3 CompliantManufacturer Lead Time: 30 week(s)Product Status: ActivePackaging: BoxDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Box |
| Package / Case | Module |
| Mounting Type | Chassis Mount |
| Configuration | 2 N-Channel (Half Bridge) |
| Operating Temperature | -40°C ~ 175°C (TJ) |
| Technology | Silicon Carbide (SiC) |
| Power - Max | - |
| Drain to Source Voltage (Vdss) | 1200V (1.2kV) |
| Current - Continuous Drain (Id) @ 25°C | 220A |
| Input Capacitance (Ciss) (Max) @ Vds | 24200pF @ 800V |
| Rds On (Max) @ Id, Vgs | 4.44mOhm @ 280A, 18V |
| Gate Charge (Qg) (Max) @ Vgs | 800nC @ 18V |
| FET Feature | - |
| Vgs(th) (Max) @ Id | 5.1V @ 112mA |
| Supplier Device Package | AG-62MMHB |
| Grade | - |
| Qualification | - |
Request a Quote
