BAW56UE6327HTSA1
DIODE ARRAY GP 80V 200MA SC74-6Manufacturer: Infineon Technologies
Categories: Diode Arrays
Quality Control: Learn More
Infineon Technologies BAW56UE6327HTSA1 is a diode array featuring two pairs of common anode configurations. This component, housed in an SC-74, SOT-457 package, offers a DC reverse voltage rating of 80V and a maximum forward voltage of 1.25V at 150mA. Each diode within the array supports an average rectified current of 200mA. The device exhibits a reverse leakage current of 150 nA at 70V and a typical reverse recovery time of 4 ns, indicating its suitability for small signal applications. With a maximum junction operating temperature of 150°C and surface mount mounting type, this diode array is commonly employed in telecommunications and industrial control systems. It is supplied in Tape & Reel (TR) packaging.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | SC-74, SOT-457 |
| Mounting Type | Surface Mount |
| Speed | Small Signal =< 200mA (Io), Any Speed |
| Reverse Recovery Time (trr) | 4 ns |
| Technology | Standard |
| Diode Configuration | 2 Pair Common Anode |
| Current - Average Rectified (Io) (per Diode) | 200mA (DC) |
| Supplier Device Package | PG-SC74-6 |
| Operating Temperature - Junction | 150°C (Max) |
| Voltage - DC Reverse (Vr) (Max) | 80 V |
| Voltage - Forward (Vf) (Max) @ If | 1.25 V @ 150 mA |
| Current - Reverse Leakage @ Vr | 150 nA @ 70 V |
