BAW56SH6727XTSA1
DIODE ARRAY GP 80V 200MA SOT363Manufacturer: Infineon Technologies
Categories: Diode Arrays
Quality Control: Learn More
Infineon Technologies BAW56SH6727XTSA1 is a diode array featuring two pairs of common anode configurations. This surface mount device, housed in a PG-SOT363-PO (SOT-363) package, offers a maximum DC reverse voltage of 80V and a rectified current handling capability of 200mA per diode. The device exhibits a typical forward voltage of 1.25V at 150mA and a reverse leakage current of 150 nA at 70V. With a reverse recovery time of 4 ns, it is suitable for general-purpose and small signal applications. The operating junction temperature range extends up to 150°C. This component finds application in various electronic systems, including telecommunications and consumer electronics. The BAW56SH6727XTSA1 is supplied on tape and reel.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 6-VSSOP, SC-88, SOT-363 |
| Mounting Type | Surface Mount |
| Speed | Small Signal =< 200mA (Io), Any Speed |
| Reverse Recovery Time (trr) | 4 ns |
| Technology | Standard |
| Diode Configuration | 2 Pair Common Anode |
| Current - Average Rectified (Io) (per Diode) | 200mA (DC) |
| Supplier Device Package | PG-SOT363-PO |
| Operating Temperature - Junction | 150°C (Max) |
| Voltage - DC Reverse (Vr) (Max) | 80 V |
| Voltage - Forward (Vf) (Max) @ If | 1.25 V @ 150 mA |
| Current - Reverse Leakage @ Vr | 150 nA @ 70 V |
