BAV74
DIODE ARRAY GP 50V 200MA SOT23-3Manufacturer: Infineon Technologies
Categories: Diode Arrays
Quality Control: Learn More
Infineon Technologies BAV74 is a dual diode array featuring a common cathode configuration. This small signal diode array offers a maximum DC reverse voltage of 50V and a continuous forward current of 200mA per diode. The forward voltage drop is specified at 1V maximum at 100mA. With a reverse leakage of 100 nA at 50V, it is suitable for applications requiring minimal leakage. The device exhibits a reverse recovery time of 4 ns, facilitating efficient switching. Operating at a maximum junction temperature of 150°C, the BAV74 is housed in a SOT-23-3 (TO-236-3, SC-59) surface-mount package, commonly found in telecommunications and industrial automation systems.
Additional Information
Series: -RoHS Status: RoHS non-compliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Bulk |
| Package / Case | TO-236-3, SC-59, SOT-23-3 |
| Mounting Type | Surface Mount |
| Speed | Small Signal =< 200mA (Io), Any Speed |
| Reverse Recovery Time (trr) | 4 ns |
| Technology | Standard |
| Diode Configuration | 1 Pair Common Cathode |
| Current - Average Rectified (Io) (per Diode) | 200mA |
| Supplier Device Package | SOT-23-3 |
| Operating Temperature - Junction | 150°C (Max) |
| Voltage - DC Reverse (Vr) (Max) | 50 V |
| Voltage - Forward (Vf) (Max) @ If | 1 V @ 100 mA |
| Current - Reverse Leakage @ Vr | 100 nA @ 50 V |
