S6BP203A8FST2B000
IC REG BCK-BST 3.3V 2.4A 16TSSOPManufacturer: Infineon Technologies
Categories: DC DC Switching Regulators
Quality Control: Learn More
Infineon Technologies S6BP203A8FST2B000 is a highly efficient buck-boost switching regulator IC designed for automotive applications. This AEC-Q100 qualified component offers a fixed 3.3V positive output with an impressive 2.4A current capability. Its versatile buck-boost topology supports input voltages from 2.5V to 42V, enabling seamless voltage conversion for a wide range of power management needs. The device operates with a selectable switching frequency between 200kHz and 2.1MHz, allowing for optimization between efficiency and component size. Featuring a synchronous rectifier for enhanced efficiency and a 16-TSSOP (0.173", 4.40mm Width) exposed pad package for superior thermal performance, this IC is suitable for demanding automotive environments including infotainment systems and advanced driver-assistance systems. The S6BP203A8FST2B000 is supplied in Tape & Reel packaging.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 16-TSSOP (0.173"", 4.40mm Width) Exposed Pad |
| Output Type | Fixed |
| Mounting Type | Surface Mount |
| Number of Outputs | 1 |
| Function | Step-Up/Step-Down |
| Current - Output | 2.4A |
| Operating Temperature | -40°C ~ 125°C (TA) |
| Output Configuration | Positive |
| Frequency - Switching | 200kHz ~ 2.1MHz |
| Voltage - Input (Max) | 42V |
| Topology | Buck-Boost |
| Supplier Device Package | 16-TSSOP |
| Synchronous Rectifier | Yes |
| Voltage - Output (Max) | - |
| Voltage - Input (Min) | 2.5V |
| Voltage - Output (Min/Fixed) | 3.3V |
| Grade | Automotive |
| Qualification | AEC-Q100 |
