IR3839MTRPBF
IC REG BUCK ADJ 6A 17QFNManufacturer: Infineon Technologies
Categories: DC DC Switching Regulators
Quality Control: Learn More
Infineon Technologies SupIRBuck® series IR3839MTRPBF is an adjustable, positive output buck switching regulator IC. This highly efficient DC-DC converter provides up to 6A of output current and features a wide switching frequency range from 225kHz to 1.65MHz. Designed for demanding applications, it operates with an input voltage range of 7V to 16V and offers an adjustable output voltage from 0.6V up to 14.4V. The IR3839MTRPBF incorporates a synchronous rectifier for enhanced efficiency. Packaged in a 17-PowerVQFN (5x6) and supplied on tape and reel, this component is suitable for surface mounting. Its robust performance makes it a key component in automotive, industrial, and data center power supply designs.
Additional Information
Series: SupIRBuck®RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 17-PowerVQFN |
| Output Type | Adjustable |
| Mounting Type | Surface Mount |
| Number of Outputs | 1 |
| Function | Step-Down |
| Current - Output | 6A |
| Operating Temperature | -40°C ~ 125°C (TJ) |
| Output Configuration | Positive |
| Frequency - Switching | 225kHz ~ 1.65MHz |
| Voltage - Input (Max) | 16V |
| Topology | Buck |
| Supplier Device Package | 17-PQFN (5x6) |
| Synchronous Rectifier | Yes |
| Voltage - Output (Max) | 14.4V |
| Voltage - Input (Min) | 7V |
| Voltage - Output (Min/Fixed) | 0.6V |
