IRU3038CF
IC REG CTRLR BUCK/BOOST 14TSSOPManufacturer: Infineon Technologies
Categories: DC DC Switching Controllers
Quality Control: Learn More
Infineon Technologies IRU3038CF is a positive output, single-phase buck/boost DC-DC controller IC. This device offers step-up and step-down voltage conversion capabilities, operating with a supply voltage range of 4.2V to 25V and a switching frequency of 200kHz. Key control features include frequency control and soft start, with a maximum duty cycle of 90%. The IRU3038CF utilizes synchronous rectification and is housed in a 14-TSSOP package (0.173", 4.40mm width) suitable for surface mounting. It is designed for applications requiring flexible power conversion, commonly found in industrial and automotive power management systems. The component operates within an ambient temperature range of 0°C to 70°C.
Additional Information
Series: -RoHS Status: RoHS non-compliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TubeDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tube |
| Package / Case | 14-TSSOP (0.173"", 4.40mm Width) |
| Output Type | Transistor Driver |
| Mounting Type | Surface Mount |
| Function | Step-Up, Step-Down |
| Operating Temperature | 0°C ~ 70°C (TA) |
| Output Configuration | Positive |
| Frequency - Switching | 200kHz |
| Topology | Buck, Boost |
| Voltage - Supply (Vcc/Vdd) | 4.2V ~ 25V |
| Supplier Device Package | 14-TSSOP |
| Synchronous Rectifier | Yes |
| Control Features | Frequency Control, Soft Start |
| Serial Interfaces | - |
| Output Phases | 1 |
| Duty Cycle (Max) | 90% |
| Clock Sync | No |
| Number of Outputs | 1 |
