CY7B991V-7JXCT
IC CLK BUFFER 8:8 80MHZ 32PLCCManufacturer: Infineon Technologies
Categories: Clock Buffers, Drivers
Quality Control: Learn More
Infineon Technologies CY7B991V-7JXCT is an 8:8 clock buffer/driver from the RoboClock™ series, operating up to 80 MHz. This component features 3-state input and LVTTL output, with a 2.97V to 3.63V supply voltage. The device is packaged in a 32-PLCC (J-Lead) form factor, supplied on tape and reel. Its differential input/output capability is not specified. This clock buffer is suitable for applications requiring precise clock distribution in areas such as high-speed computing, telecommunications, and industrial automation. The CY7B991V-7JXCT provides a single circuit for clock buffering needs.
Additional Information
Series: RoboClock™RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 32-LCC (J-Lead) |
| Number of Circuits | 1 |
| Mounting Type | Surface Mount |
| Output | LVTTL |
| Type | Buffer/Driver |
| Input | 3-State |
| Operating Temperature | 0°C ~ 70°C |
| Voltage - Supply | 2.97V ~ 3.63V |
| Ratio - Input:Output | 8:8 |
| Differential - Input:Output | Yes/No |
| Supplier Device Package | 32-PLCC (11.43x13.97) |
| Frequency - Max | 80 MHz |
