CY8CLED02-16SXI
IC MCU 8BIT 4KB FLASH 16SOICManufacturer: Infineon Technologies
Categories: Application Specific Microcontrollers
Quality Control: Learn More
Infineon Technologies EZ-Color™ CY8CLED series CY8CLED02-16SXI is an 8-bit microcontroller with 4KB of FLASH program memory and 256 x 8 bytes of RAM. This device features the M8C core and supports multiple communication interfaces including I2C, IrDA, SPI, and UART/USART. With 12 programmable I/O pins, it is suitable for surface mount applications and operates within a voltage range of 2.4V to 5.25V. The CY8CLED02-16SXI is packaged in a 16-SOIC (0.154", 3.90mm width) and is supplied in tubes. Its primary application is as an HB LED controller, finding use in lighting and display systems. The operating temperature range for this component is -40°C to 85°C.
Additional Information
Series: EZ-Color™ CY8CLEDRoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TubeDownload Free CAD Model:
Technical Details:
| Packaging | Tube |
| Package / Case | 16-SOIC (0.154"", 3.90mm Width) |
| Mounting Type | Surface Mount |
| Interface | I2C, IrDA, SPI, UART/USART |
| RAM Size | 256 x 8 |
| Operating Temperature | -40°C ~ 85°C |
| Voltage - Supply | 2.4V ~ 5.25V |
| Controller Series | CY8CLED |
| Program Memory Type | FLASH (4kB) |
| Applications | HB LED Controller |
| Core Processor | M8C |
| Supplier Device Package | 16-SOIC |
| Number of I/O | 12 |
| Programmable | Not Verified |
