CY8C20247-24LKXIT
IC CAPSENCE 16K FLASH 16QFNManufacturer: Infineon Technologies
Categories: Application Specific Microcontrollers
Quality Control: Learn More
Infineon Technologies CY8C20247-24LKXIT, a CapSense® controller from the CY8C20xx7/S series, offers advanced capacitive sensing capabilities. This electronic component features a M8C core processor and 16KB of FLASH program memory, complemented by 2K x 8 RAM. Its 16-UFQFN package, specifically a 16-QFN (3x3) in Tape & Reel (TR) packaging, is designed for surface mount applications. The device supports I2C and SPI interfaces, with 13 available I/O pins. Operating within a voltage range of 1.71V to 5.5V and an industrial temperature range of -40°C to 85°C, the CY8C20247-24LKXIT is well-suited for a variety of capacitive touch interface designs across consumer electronics and industrial control systems.
Additional Information
Series: CapSense® ControllersRoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 16-UFQFN |
| Mounting Type | Surface Mount |
| Interface | I2C, SPI |
| RAM Size | 2K x 8 |
| Operating Temperature | -40°C ~ 85°C |
| Voltage - Supply | 1.71V ~ 5.5V |
| Controller Series | CY8C20xx7/S |
| Program Memory Type | FLASH (16KB) |
| Applications | Capacitive Sensing |
| Core Processor | M8C |
| Supplier Device Package | 16-QFN (3x3) |
| Number of I/O | 13 |
| Programmable | Not Verified |
