TLE5009E2010FUMA1
SENSOR ANGLE 360DEG SOLDER TABManufacturer: Infineon Technologies
Categories: Angle, Linear Position Measuring
Quality Control: Learn More
Infineon Technologies TLE5009E2010FUMA1 is a magnetoresistive sensor designed for 360-degree angle measurement. This component utilizes a magnetoresistive technology to detect the magnetic field from an external magnet, providing both sine and cosine analog voltage outputs. The device is qualified to AEC-Q100 standards, indicating its suitability for automotive applications. It features a surface mountable PG-DSO-8 package with gull wing termination, compatible with standard pick-and-place assembly. Operating within a voltage supply range of 4.5V to 5.5V and an extended temperature range of -40°C to 150°C, the TLE5009E2010FUMA1 is engineered for continuous angular position sensing in demanding environments. Its robust design and precise output characteristics make it ideal for applications requiring accurate angle detection, such as automotive steering and position sensing systems.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: 18 week(s)Product Status: ActivePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 8-SOIC (0.154"", 3.90mm Width) |
| Mounting Type | Surface Mount |
| Output | Analog Voltage |
| Operating Temperature | -40°C ~ 150°C |
| Termination Style | Gull Wing |
| Voltage - Supply | 4.5V ~ 5.5V |
| Linearity | - |
| Linear Range | - |
| Actuator Type | External Magnet, Not Included |
| Technology | Magnetoresistive |
| Resistance Tolerance | - |
| For Measuring | Angle |
| Supplier Device Package | PG-DSO-8 |
| Rotation Angle - Electrical, Mechanical | 0° ~ 360°, Continuous |
| Output Signal | Cosine, Sine |
| Grade | Automotive |
| Programmable | - |
| Qualification | AEC-Q100 |
