ICE3B1565JFKLA1
IC OFFLINE SWITCH FLYBACK 8DIPManufacturer: Infineon Technologies
Categories: AC DC Converters, Offline Switches
Quality Control: Learn More
Infineon Technologies' ICE3B1565JFKLA1 is an offline PWM controller featuring the CoolSET™F3 series, designed for flyback converter topologies. This 8-pin DIP component operates at a switching frequency of 67kHz with an internal 650V CoolMOS™ power transistor. It offers a 75% duty cycle and supports high efficiency with integrated soft-start functionality. The device includes comprehensive protection features such as current limiting, open circuit, overload, over-temperature, and over-voltage protection. Designed for through-hole mounting, the ICE3B1565JFKLA1 is suitable for applications requiring isolated power conversion, including consumer electronics, home appliances, and industrial power supplies. Its operating temperature range is -25°C to 130°C (TJ).
Additional Information
Series: CoolMOS™, CoolSET™F3RoHS Status: ROHS3 CompliantManufacturer Lead Time: 13 week(s)Product Status: Not For New DesignsPackaging: TubeDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tube |
| Package / Case | 8-DIP (0.300"", 7.62mm) |
| Mounting Type | Through Hole |
| Operating Temperature | -25°C ~ 130°C (TJ) |
| Duty Cycle | 75% |
| Frequency - Switching | 67kHz |
| Internal Switch(s) | Yes |
| Voltage - Breakdown | 650V |
| Output Isolation | Isolated |
| Topology | Flyback |
| Voltage - Supply (Vcc/Vdd) | 10.3V ~ 26V |
| Supplier Device Package | PG-DIP-8 |
| Fault Protection | Current Limiting, Open Circuit, Over Load, Over Temperature, Over Voltage |
| Voltage - Start Up | 18 V |
| Control Features | Soft Start |
| Power (Watts) | 42 W |
