LBW7P-1T04R
LBW FLUSH PILOT 24V REDManufacturer: IDEC
Categories: Panel Indicators, Pilot Lights
Quality Control: Learn More
IDEC LBW Series LED Panel Indicator, Part Number LBW7P-1T04R. This illuminated pilot light features a 24V AC/DC rating and a red LED lamp. Designed for panel mounting with a standard 22.50mm square cutout, it offers excellent visibility and IP65 ingress protection for robust operation in demanding environments. The unit utilizes solder lug terminations for secure connections. Applications include industrial automation, control panels, and equipment status indication. The lens is a square, flat-top design with a 26.00mm diameter.
Additional Information
Series: LBWRoHS Status: ROHS3 CompliantManufacturer Lead Time: 35 week(s)Product Status: ActivePackaging: BoxDatasheet:Download Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Box |
| Current | - |
| Voltage | 24V |
| Type | LED |
| Millicandela Rating | - |
| Termination Style | Solder Lug |
| Lens Color | - |
| Viewing Angle | - |
| Ingress Protection | IP65 |
| Ratings | AC/DC |
| Panel Cutout Dimensions | 0.89"" x 0.89"" (22.50mm x 22.50mm) |
| Wavelength - Peak | - |
| Lens Transparency | - |
| Lamp Color | Red |
| Panel Cutout Shape | Square |
| Lens Style | Square with Flat Top |
| Lens Size | 26.00mm |
