LBW6P-1T04G
LBW FLUSH PILOT 24V GREENManufacturer: IDEC
Categories: Panel Indicators, Pilot Lights
Quality Control: Learn More
IDEC LBW series LED panel indicator, part number LBW6P-1T04G. This illuminated push button features a flush mount design with a 24V AC/DC rating and a green LED lamp. The unit conforms to IP65 ingress protection standards, ensuring robust performance in demanding environments. Terminations are provided via solder lugs for reliable connections. The round lens, with a 26.00mm diameter and flat top profile, is designed for a 22.30mm (0.88") round panel cutout. This component is commonly utilized in industrial automation, control panels, and equipment signaling applications where clear visual indication is critical.
Additional Information
Series: LBWRoHS Status: ROHS3 CompliantManufacturer Lead Time: 35 week(s)Product Status: ActivePackaging: BoxDatasheet:Download Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Box |
| Current | - |
| Voltage | 24V |
| Type | LED |
| Millicandela Rating | - |
| Termination Style | Solder Lug |
| Lens Color | - |
| Viewing Angle | - |
| Ingress Protection | IP65 |
| Ratings | AC/DC |
| Panel Cutout Dimensions | 0.88"" (22.30mm) |
| Wavelength - Peak | - |
| Lens Transparency | - |
| Lamp Color | Green |
| Panel Cutout Shape | Round |
| Lens Style | Round with Flat Top |
| Lens Size | 26.00mm Dia |
