AP8M211-PW
PILOT LIGHT 8MM AP8 SERIESManufacturer: IDEC
Categories: Panel Indicators, Pilot Lights
Quality Control: Learn More
IDEC AP8 Series AP8M211-PW is an 8mm LED panel indicator. This component features a white LED lamp and a domed round lens, providing a clear visual indication. Designed for panel mounting with an 8.10mm (0.32") round cutout, it offers solder lug termination for secure connections. The AP8M211-PW operates at 12V and draws a current of 15mA, compatible with both AC and DC power sources. Its IP40 ingress protection rating makes it suitable for use in industrial control panels, automation systems, and general equipment status indication where a robust and reliable pilot light is required.
Additional Information
Series: AP8RoHS Status: RoHS CompliantManufacturer Lead Time: 27 week(s)Product Status: ActivePackaging: BulkDownload Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Bulk |
| Current | 15mA |
| Voltage | 12V |
| Type | LED |
| Millicandela Rating | - |
| Termination Style | Solder Lug |
| Lens Color | - |
| Viewing Angle | - |
| Ingress Protection | IP40 |
| Ratings | AC/DC |
| Panel Cutout Dimensions | 0.32"" (8.10mm) |
| Wavelength - Peak | - |
| Lens Transparency | - |
| Lamp Color | White |
| Panel Cutout Shape | Round |
| Lens Style | Round with Domed Top |
| Lens Size | 8.00mm Dia |
