TSCSNBN030PGUCV
SENSOR 30PSIG 0.19"" .02625V 4SIPManufacturer: Honeywell Sensing and Productivity Solutions
Categories: Pressure Sensors, Transducers
Quality Control: Learn More
Honeywell Sensing and Productivity Solutions TruStability® TSC series TSCSNBN030PGUCV is a vented gauge pressure sensor with a 30 PSI (206.84kPa) operating pressure range. This component features a 5V output across a 0 mV to 26.25 mV span, utilizing a Wheatstone bridge configuration. The device offers ±0.15% accuracy and is temperature compensated, operating within a -40°C to 85°C temperature range. It is designed for board mounting with a through-hole termination style. The sensor utilizes a male 0.19" (4.8mm) tube port with dual, same-side ports. This component is suitable for applications in industrial and medical equipment.
Additional Information
Series: TruStability® TSCRoHS Status: Request inventory verificationManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Features | Temperature Compensated |
| Packaging | Bulk |
| Package / Case | 4-SIP, Dual Ports, Same Side |
| Output Type | Wheatstone Bridge |
| Mounting Type | Through Hole |
| Output | 0 mV ~ 26.25 mV (5V) |
| Operating Pressure | 30PSI (206.84kPa) |
| Pressure Type | Vented Gauge |
| Accuracy | ±0.15% |
| Operating Temperature | -40°C ~ 85°C |
| Termination Style | PC Pin |
| Voltage - Supply | 1.5V ~ 12V |
| Port Size | Male - 0.19"" (4.8mm) Tube, Dual |
| Applications | Board Mount |
| Supplier Device Package | 4-SIP |
| Port Style | Barbless |
| Maximum Pressure | 115PSI (792.9kPa) |
