SSCSMNN050KGAF5
SENSOR 7.25PSIG 4.7V 4SIPManufacturer: Honeywell Sensing and Productivity Solutions
Categories: Pressure Sensors, Transducers
Quality Control: Learn More
Honeywell Sensing and Productivity Solutions TruStability® SSC SSCSMNN050KGAF5 is a vented gauge pressure sensor with a 7.25 PSI (50 kPa) operating pressure range. This amplified, temperature-compensated sensor provides an analog voltage output from 0.2 V to 4.7 V, with a supply voltage range of 4.75 V to 5.25 V. The device features ±0.25% accuracy and is housed in a 4-SIP module for through-hole mounting. Its robust design and reliable performance make it suitable for demanding applications in industries such as industrial automation, medical equipment, and HVAC systems. The sensor's PC pin termination style facilitates integration into printed circuit board designs.
Additional Information
Series: TruStability® SSCRoHS Status: Request inventory verificationManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Features | Amplified Output, Temperature Compensated |
| Packaging | Bulk |
| Package / Case | 4-SIP Module |
| Output Type | Analog Voltage |
| Mounting Type | Through Hole |
| Output | 0.2 V ~ 4.7 V |
| Operating Pressure | 7.25PSI (50kPa) |
| Pressure Type | Vented Gauge |
| Accuracy | ±0.25% |
| Operating Temperature | -40°C ~ 85°C |
| Termination Style | PC Pin |
| Voltage - Supply | 4.75V ~ 5.25V |
| Port Size | - |
| Applications | Board Mount |
| Supplier Device Package | 4-SIP |
| Port Style | No Port |
| Maximum Pressure | - |
