SSCSHNT060PAAA5
SENSOR 60PSIA 0.19"" 4.5V 4SIPManufacturer: Honeywell Sensing and Productivity Solutions
Categories: Pressure Sensors, Transducers
Quality Control: Learn More
Honeywell Sensing and Productivity Solutions TruStability® SSC series pressure sensor, part number SSCSHNT060PAAA5. This absolute pressure sensor offers a 60 PSIa (413.69kPa) operating range with a high accuracy of ±0.25%. Featuring an amplified analog voltage output from 0.5 V to 4.5 V, it is designed for board mount applications. The sensor utilizes a 0.19" (4.78mm) barbed male port for pressure connection. Its 4-SIP package with side port and through-hole mounting facilitates integration into various systems. Operating across a temperature range of -40°C to 85°C, this component is suitable for demanding environments. The specified supply voltage is 4.75V to 5.25V. This sensor is commonly found in industrial automation, medical devices, and HVAC systems.
Additional Information
Series: TruStability® SSCRoHS Status: Request inventory verificationManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Features | Amplified Output, Temperature Compensated |
| Packaging | Bulk |
| Package / Case | 4-SIP, Side Port |
| Output Type | Analog Voltage |
| Mounting Type | Through Hole |
| Output | 0.5 V ~ 4.5 V |
| Operating Pressure | 60PSI (413.69kPa) |
| Pressure Type | Absolute |
| Accuracy | ±0.25% |
| Operating Temperature | -40°C ~ 85°C |
| Termination Style | PC Pin |
| Voltage - Supply | 4.75V ~ 5.25V |
| Port Size | Male - 0.19"" (4.78mm) Tube |
| Applications | Board Mount |
| Supplier Device Package | 4-SIP |
| Port Style | Barbed |
| Maximum Pressure | 120PSI (827.37kPa) |
