SSCSGNN015PAAA5
SENSOR 15PSIA 0.19"" 4.5V 4SIPManufacturer: Honeywell Sensing and Productivity Solutions
Categories: Pressure Sensors, Transducers
Quality Control: Learn More
Honeywell Sensing and Productivity Solutions TruStability® SSC SSCSGNN015PAAA5 is a board mount absolute pressure sensor with a 15 PSI (103.42 kPa) operating pressure range. This component features an amplified and temperature-compensated analog voltage output, spanning from 0.5 V to 4.5 V, with a supply voltage range of 4.75 V to 5.25 V. The sensor utilizes a 0.19" (4.78mm) barbed male port for pressure connection and is housed in a 4-SIP package with side port termination. Designed for high accuracy, it offers a ±0.25% total error band. Applications include industrial automation, medical equipment, and HVAC systems. The operating temperature range is -40°C to 85°C, and the maximum pressure rating is 30 PSI (206.84 kPa).
Additional Information
Series: TruStability® SSCRoHS Status: Request inventory verificationManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Features | Amplified Output, Temperature Compensated |
| Packaging | Bulk |
| Package / Case | 4-SIP, Side Port |
| Output Type | Analog Voltage |
| Mounting Type | Through Hole |
| Output | 0.5 V ~ 4.5 V |
| Operating Pressure | 15PSI (103.42kPa) |
| Pressure Type | Absolute |
| Accuracy | ±0.25% |
| Operating Temperature | -40°C ~ 85°C |
| Termination Style | PC Pin |
| Voltage - Supply | 4.75V ~ 5.25V |
| Port Size | Male - 0.19"" (4.78mm) Tube |
| Applications | Board Mount |
| Supplier Device Package | 4-SIP |
| Port Style | Barbed |
| Maximum Pressure | 30PSI (206.84kPa) |
